Name: DS1158-01 SMA Connector Socket Vertical Through Type L=13.7mm - Cirkit Electro Components
SKU: DS1158-01

DS1158-01 SMA Connector Socket Vertical Through Type L=13.7mm

SMA Connector Socket Vertical Through Type L=13.7mm

by Connfly

SKU: DS1158-01 Category: Uncategorized Brand: Connfly

Specifications

Color	White
Packing Type	Tray
Mounting Type	V/T
Shell Plating	Gold flash
Contact Finish	Gold flash
Shell Material	Copper alloy
Contact Material	Copper alloy
Withstand Voltage	500V AC 1minitue
Contact Resistance	10mΩ maximum
Plastic Flame Rating	UL94 V0
Insulation Resistance	1000MΩ minimum
Operating Temperature	(-40~+125)℃
Soldering Temperature	250℃
Connector / Cable Type	RF Series
Housing / Plastic Material	PTFE
Manufacturer	Connfly
Product Name	SMA Connector Socket Vertical Through Type L=13.7mm

DS1158-01 SMA Connector Socket Vertical Through Type L=13.7mm
