Name: DS1110-13 Micro Jack Total Length=45.5mm Ref(Pin Ø1.0) Push Pull Type. - Cirkit Electro Components
SKU: DS1110-13

DS1110-13 Micro Jack Total Length=45.5mm Ref(Pin Ø1.0) Push Pull Type.

Micro Jack Total Length=45.5mm Ref(Pin Ø1.0) Push Pull Type.

by Connfly

SKU: DS1110-13 Category: Round Connector Series Brand: Connfly

Specifications

Color	Blue
RoHS 2.0	Compliant
Shelf Life	3~6 months
AQL Standard	0.65
Mounting Type	Solder
Contact Finish	Gold Plating
Contact Material	Copper alloy
Withstand Voltage	1000V AC 1 minute
Contact Resistance	20mΩ maximum
Plastic Flame Rating	UL94V-0/UL94V-2/UL94HB
Current Rating (Amps)	5A Max
Insulation Resistance	1000MΩ minimum
Connector / Cable Type	Round Connector, 1394, DIN 41612 Series
Housing / Plastic Material	Thermoplastic
Manufacturer	Connfly
Product Name	Micro Jack Total Length=45.5mm Ref(Pin Ø1.0) Push Pull Type.

DS1110-13 Micro Jack Total Length=45.5mm Ref(Pin Ø1.0) Push Pull Type.
