Name: DS1044 2.54mm ZIF Socket One By One DIP Type - Cirkit Electro Components
SKU: DS1044

DS1044 2.54mm ZIF Socket One By One DIP Type

2.54mm ZIF Socket One By One DIP Type

by Connfly

SKU: DS1044 Category: Test Board Series Brand: Connfly

Specifications

Color	Green/Black/Blue
Pitch	2.54mm
RoHS 2.0	Compliant
Shelf Life	3~6 months
AQL Standard	0.65
Packing Type	Tube
Mounting Type	V/T
Contact Finish	Gold plating/Tin plating
Voltage Rating	50V DC
Contact Material	Copper alloy
Withstand Voltage	500V AC 1 minute
Contact Resistance	50mΩ maximum
Plastic Flame Rating	UL94V-0
Current Rating (Amps)	100mA
Insulation Resistance	1000MΩ minimum
Operating Temperature	-40~+105℃
Soldering Temperature	250±5℃
Connector / Cable Type	Bread Board, Jumper Wire, Wash W/ Crimp Wire Series
Housing / Plastic Material	PBT
Manufacturer	Connfly
Product Name	2.54mm ZIF Socket One By One DIP Type

DS1044 2.54mm ZIF Socket One By One DIP Type
