2.54mm Switch V/T & SMT W/ Mylar Type
by Connfly
Product successfully added to the Quote List
Specifications
| Mounting Type | |
|---|---|
| Contact Material | |
| Withstand Voltage | |
| Plastic Flame Rating | |
| Type | DIP Switch |
| Color | Black |
| Pitch | 2.54mm |
| RoHS 2.0 | Compliant |
| Shelf Life | 3~6 months |
| AQL Standard | 0.65 |
| Packing Type | Tape and reel |
| Contact Finish | Gold plating |
| Current Rating | 25mA |
| Contact Resistance | 100mΩ maximum |
| Insulation Resistance | 1000MΩ minimum |
| Operating Temperature | -25~+70℃ |
| Soldering Temperature | 260±5℃ |
| Voltage - Rated / Coil | 24V AC/DC |
| Housing / Plastic Material | High-temp plastic |
| Number of Positions / Contacts | 2~12 |
| Manufacturer | Connfly |
| Product Name | 2.54mm Switch V/T & SMT W/ Mylar Type |
